Mastering DNS on Windows Server: A Step-by-Step Installation and Configuration Guide

Updated: • 0 • min read
Table of Contents

Mastering DNS on Windows Server

What is DNS in Windows Server?

The Domain Name System (DNS) is a fundamental service that underpins the functionality of the internet and modern network infrastructures, especially within business environments utilizing Windows Server. Imagine the internet as a vast phonebook, but instead of names and phone numbers, it deals with hostnames (like website addresses) and IP addresses (numerical labels that identify devices on a network). DNS acts as this translator, allowing users to access websites and services using easy-to-remember domain names, rather than complex IP addresses.

When you type a web address, such as www.example.com, into your browser, your computer initiates a DNS query. This query is sent to a DNS server, which then searches its database to find the corresponding IP address for www.example.com. Once the IP address is found, the DNS server returns it to your computer, enabling your browser to connect to the correct web server and display the website. Without DNS, we would be forced to memorize and use numerical IP addresses for every website and online service, making the internet significantly less user-friendly. In the context of Windows Server, setting up and managing DNS is crucial for internal network resource accessibility, domain management, and ensuring seamless communication within an organization’s digital ecosystem.

Install and Configure DNS on Windows Server

Setting up DNS on Windows Server involves a series of straightforward steps. This guide will walk you through the essential configurations to get your DNS server operational. The process can be broken down into four key stages, which we will explore in detail:

  1. Assigning a Static IP Address
  2. Installing the DNS Server Role
  3. Adding DNS Records
  4. Configuring Interface Bindings (Limiting IP Addresses)

Let’s delve into each of these steps to establish a functional DNS server on your Windows Server.

1] Assign a Static IP Address

Before installing the DNS Server role, it is critical to configure your Windows Server with a static IP address. By default, most networks utilize DHCP (Dynamic Host Configuration Protocol), which automatically assigns IP addresses to devices. However, a DNS server needs a stable and unchanging IP address so that other devices can reliably locate it. If the IP address of your DNS server changes, devices attempting to use it for name resolution will fail. Therefore, assigning a static IP address is the first and foremost step in setting up a DNS server.

Here’s how to assign a static IP address on Windows Server:

  1. Open Network Connections: Click on the Start button, type “View network connections,” and select the “View network connections” Control Panel option. This will open the Network Connections window, displaying all network adapters installed in your server.

  2. Access Network Adapter Properties: Identify the network adapter you wish to configure for your DNS server (this could be an Ethernet connection or a Wireless adapter). Right-click on the chosen network adapter and select Properties from the context menu. This action will open the Properties window for that specific network adapter.

  3. Select Internet Protocol Version 4 (TCP/IPv4): In the network adapter’s Properties window, you will see a list of networking components. Scroll down and locate “Internet Protocol Version 4 (TCP/IPv4)” in the list. Select it, and then click on the Properties button below the list. This will open the Internet Protocol Version 4 (TCP/IPv4) Properties window.

  4. Configure Static IP Address Settings: In the IPv4 Properties window, you will see two sections for IP address configuration: “Obtain an IP address automatically” and “Use the following IP address.” To set a static IP, select the radio button for “Use the following IP address.” This will enable the fields for IP address, Subnet mask, and Default gateway.

    • IP address: Enter the static IP address you want to assign to your server. Choose an IP address within your network’s IP address range that is not already in use and is outside the DHCP range if DHCP is used on your network. For example, if your network range is 192.168.1.0/24 and your DHCP range is 192.168.1.100 - 192.168.1.200, you could choose an IP address like 192.168.1.25.
    • Subnet mask: Once you enter the IP address and click into the “Subnet mask” field, it will often auto-populate based on the IP address class. For most small to medium-sized networks, the subnet mask will be 255.255.255.0. Ensure this is correct for your network configuration.
    • Default gateway: The default gateway is the IP address of your router or the device that connects your network to other networks, including the internet. Typically, this is the IP address of your router. For example, it might be 192.168.1.1. This is crucial for your server to communicate with networks outside of your local network.

  5. Configure DNS Server Addresses: In the same IPv4 Properties window, you will see sections for “Preferred DNS server” and “Alternate DNS server”.

    • Preferred DNS server: For a DNS server you are setting up on this server, you can initially set the Preferred DNS server to the server’s own static IP address you just configured (e.g., 192.168.1.25 in our example). This is known as a loopback address configuration and allows the server to use itself for DNS resolution after the DNS role is installed. You can also use other internal DNS servers if they exist.
    • Alternate DNS server: For redundancy and to resolve external domain names (those on the internet), it is highly recommended to configure an Alternate DNS server. Public DNS servers like Google Public DNS (8.8.8.8 and 8.8.4.4) or Cloudflare DNS (1.1.1.1 and 1.0.0.1) are excellent choices. These external DNS servers will ensure your server can resolve names on the internet.

  6. Apply and Close: After entering all the IP address, subnet mask, default gateway, and DNS server information, click OK in the IPv4 Properties window. Then, click Close in the network adapter’s Properties window.

  7. Reboot the Server: For the static IP configuration to fully take effect, it is recommended to reboot your Windows Server. This ensures all network services are updated with the new IP address settings.

By completing these steps, you have successfully assigned a static IP address to your Windows Server, which is a prerequisite for installing and configuring the DNS Server role.

2] Install DNS Role from Roles and Features

With a static IP address assigned, the next step is to install the DNS Server role on your Windows Server. Windows Server utilizes a Role and Features-based installation system, making it easy to add server functionalities like DNS. The Server Manager is the central tool for managing server roles and features.

Follow these steps to install the DNS Server role:

  1. Open Server Manager: If Server Manager does not open automatically upon server startup, you can manually open it by clicking on the Start button and selecting Server Manager from the Windows Administrative Tools menu, or by simply typing “Server Manager” in the Start search bar.

  2. Initiate Add Roles and Features Wizard: In the Server Manager dashboard, locate the “Manage” menu in the top right corner. Click on “Manage” and then select “Add Roles and Features”. This will launch the Add Roles and Features Wizard, which guides you through the role installation process.

  3. Before You Begin: The “Before You Begin” page of the wizard provides preliminary information. Review this if it’s your first time, and then click “Next” to proceed.

  4. Installation Type: On the “Select installation type” page, choose “Role-based or feature-based installation”. This option is used for installing server roles like DNS Server. Click “Next”.

  5. Server Selection: On the “Select destination server” page, choose “Select a server from the server pool”. In most cases, you will be installing the DNS role on the local server you are currently working on, which should be selected by default. Verify that the correct server is selected and click “Next”.

  6. Select Server Roles: The “Select server roles” page is where you choose the roles to install. In the list of roles, find and check the box next to “DNS Server”. When you select “DNS Server,” a pop-up window might appear, prompting you to add required features for DNS Server. Click “Add Features” in this pop-up window to automatically include any necessary components. After adding features (if prompted), click “Next”.

  7. Select Features: The “Select features” page allows you to install additional features. For a basic DNS server setup, you typically do not need to select any additional features at this stage. You can review the list, but for now, simply click “Next” to skip this step.

  8. DNS Server Role Information: The “DNS Server” page provides an overview of the DNS Server role and its functionalities. Read the information provided to understand more about DNS Server. Click “Next” to continue.

  9. Confirmation: The “Confirm installation selections” page summarizes the roles and features you have chosen to install. Review the selections to ensure “DNS Server” is listed. It is highly recommended to check the box “Restart the destination server automatically if required”. This allows the server to automatically reboot if the installation process necessitates a restart. After reviewing and confirming your selections, click “Install”.

  10. Installation Progress and Completion: The installation process will now begin. You can monitor the progress on the “Installation progress” page. Once the installation is complete, you will see a “Installation succeeded on [Your Server Name]” message on the “Installation results” page. Click “Close” to exit the Add Roles and Features Wizard.

After completing these steps, the DNS Server role is successfully installed on your Windows Server. To verify the installation, you can open the “Tools” menu in Server Manager. You should now see “DNS” listed as an administrative tool. Additionally, you can open Command Prompt as an administrator and use the ping localhost or ping <your_server_hostname> command. If DNS is functioning correctly, it should resolve the hostname to 127.0.0.1 (localhost) or your server’s static IP address, respectively.

3] Add a New DNS Entry

After installing the DNS Server role, the server automatically becomes an authoritative DNS server for the domain it is configured for. To make your DNS server useful, you need to add DNS records. DNS records are entries in the DNS database that map domain names and hostnames to IP addresses and other information. The most common type of DNS record is the A record (Address record), which maps a hostname to an IPv4 address.

Here’s how to add a new DNS entry (A record) in Windows Server DNS Manager:

  1. Open DNS Manager: Open Server Manager, click on “Tools” in the top right corner, and select “DNS”. This will open the DNS Manager console.

  2. Expand Server and Forward Lookup Zones: In the DNS Manager console, in the left-hand pane, you will see your DNS server listed. Expand the server by clicking on the arrow next to its name. Then, expand “Forward Lookup Zones”.

  3. Select Your Domain: Under “Forward Lookup Zones,” you will see a list of domains for which your DNS server is authoritative. Select the domain where you want to add the new DNS entry. If you haven’t created a forward lookup zone yet, you may need to create one first (this is usually done automatically if the server is joined to a domain).

  4. Create a New Host (A or AAAA) Record: Right-click in the empty space in the right-hand pane (within the selected domain zone). From the context menu, select “New Host (A or AAAA)…”. This option is used to create A records (for IPv4 addresses) and AAAA records (for IPv6 addresses). The “New Host” dialog box will appear.

  5. Enter Hostname and IP Address: In the “New Host” dialog box:

    • Name (optional): In the “Name (optional)” field, enter the hostname you want to create. This is the name that will be used to access the resource. For example, if you want to create a record for server1.example.com, you would enter server1 here. If you want to create a record for the domain itself (e.g., example.com), leave this field blank, which signifies the “@” symbol representing the zone’s root.
    • IP address: In the “IP address” field, enter the IPv4 address that corresponds to the hostname you entered. This is the IP address of the server or device you want the hostname to resolve to. For example, you might enter 192.168.1.10.

  6. Create Associated PTR Record (Optional but Recommended): Check the box labeled “Create associated pointer (PTR) record”. PTR records are used for reverse DNS lookups, mapping IP addresses back to hostnames. Creating a PTR record is generally recommended for forward and reverse DNS consistency, especially for servers and services that require reverse DNS lookups for proper functioning (like mail servers). This will automatically create a corresponding PTR record in the Reverse Lookup Zone (if configured).

  7. Add Host and Confirm: Click the “Add Host” button. A dialog box will appear confirming that the host record was successfully created. Click “OK” in the confirmation dialog box.

  8. Click “Done”: Click “Done” in the “New Host” dialog box to close it.

The new DNS entry (A record) is now created in your DNS zone. To verify that the new record is working, open Command Prompt and use the ping <hostname> command (e.g., ping server1.example.com). If DNS resolution is successful, it should resolve the hostname to the IP address you configured, and the ping command should succeed. You can also use the nslookup <hostname> command to query the DNS server and verify the record details.

Remember that DNS changes can take some time to propagate across the internet (DNS propagation). However, within your local network, the changes should be effective almost immediately after being added to your DNS server.

4] Limit IP Address (Interface Bindings)

In scenarios where a Windows Server has multiple network interfaces or IP addresses assigned to a single interface, you might want to control which IP addresses the DNS server uses to listen for and respond to DNS queries. This is known as configuring interface bindings. By default, a DNS server listens on all IP addresses configured on the server. However, you can restrict it to listen only on specific IP addresses for security or network segmentation purposes.

Here’s how to limit the IP addresses used by the DNS server:

  1. Open DNS Manager: Open Server Manager, click on “Tools”, and select “DNS” to open the DNS Manager console.

  2. Access Server Properties: In the DNS Manager console, in the left-hand pane, right-click on your DNS server name. Select “Properties” from the context menu. This will open the Properties dialog box for your DNS server.

  3. Navigate to the Interfaces Tab: In the DNS server Properties dialog box, click on the “Interfaces” tab.

  4. Configure Interface Bindings: In the “Interfaces” tab, you will see two options:

    • All IP addresses: This option is selected by default. When selected, the DNS server will listen for DNS queries on all IP addresses configured on all network interfaces of the server.
    • Only the following IP addresses: Select this option to restrict the DNS server to listen only on specific IP addresses. When you select this option, a list of IP addresses configured on the server will be displayed below.

  5. Select Specific IP Addresses: If you chose “Only the following IP addresses,” check the boxes next to the IP addresses you want the DNS server to use. Uncheck the boxes next to the IP addresses you want the DNS server to ignore for DNS queries. For example, if your server has both a public-facing IP address and a private network IP address, and you only want the DNS server to respond to queries on the private network, you would select only the private network IP address.

  6. Apply and OK: After selecting the desired IP addresses, click “Apply” and then “OK” to save the changes and close the DNS server Properties dialog box.

The DNS server service will automatically restart to apply the new interface binding settings. From this point onward, the DNS server will only listen for and respond to DNS queries on the IP addresses you have selected in the “Interfaces” tab. This feature is particularly useful in multi-homed servers or when you need to isolate DNS services to specific network segments.

Hopefully, this detailed guide provides a comprehensive understanding of how to install and configure DNS on Windows Server. By following these steps, you can establish a robust and functional DNS infrastructure for your network environment. Feel free to leave any comments or questions below!
